2 - 31
Available Memory
Memory
Bit Write TYPE Remarks
DM (data memory) 0
CH (input/output relay) 1
HR (holding relay) 2
LR (latch relay) 3
AR (alarm relay) 4
T (timer/current value) 5
C (counter/current value) 6
TU (timer [contact]) 9 Read only
CU (counter [contact]) 10 Read only
Available: Unavailable:
C
CV
Memory
Bit Write TYPE Remarks
DM (data memory) 0
CH (input/output relay) 1
AR (alarm relay) 4
T (timer/current value) 5
C (counter/current value) 6
EMn (extensional data memory) 7 * 1
TU (timer [contact]) 9 Read only
CU (counter [contact]) 10 Read only
Available: Unavailable:
<E.g.> EM0:30000
Bank No.
Address No.
2 OMRON PC• 1
*1 When using EMn (extensional data memory), specify the bank
number (CV:0 ~ 7, CS1:0 ~ C).
The assigned memory is indicated while editing the screen as
illustrated:
Memory Bit Write TYPE Remarks
DM (data memory) 0
CH (input/output relay) 1
AR (alarm relay) 4
T (timer/current value) 5
C (counter/current value) 6
EMn (extensional data memory) 7 * 1
W (internal relay) 8
TU (timer/contact) 9 Read only
CU (counter/contact) 10 Read only
Available: Unavailable:
CS1
