2 - 30
Port 0
19200bps
Even
7 (ASCII)
Internal Synchronization
0V (normally ON)
OFF
ON for RS-422
Baud Rate
Parity
Transmission
Code
Data Length
Stop Bit 2
Synchronizing Switch
CTS Switch
5V Supply Switch
Terminal Resistor
Item Setting of PC
0
19200bps
Even
7
2
Comm. Parameter of ZM-
**
3
1 : n
Command Level
1 :1/1 : n Protocol
Communication Setting
The recommended communication parameter setting of both PC and ZM-
**
is as follows:
2 OMRON PC• 1
*1 When using EMn (extensional data memory), specify the bank number 0 to 7.
The assigned memory is indicated while editing the screen as illustrated:
· If [SYSMAC C] is selected at the [Select PLC Type] dialog, set the [Trans. Mode] for [Detail] in the
[Comm. Parameter] in ZM-71SE.
Trans. Mode Contents
Trans. Mode 1 w/o sign BCD
Trans. Mode 2 w/+/- sign BCD *
1
*1 w/+/- sign BCD
It is possible to display the data for PLC data with signs + and -.
When higher 4 bits of the memory are [F or A], treat the data as the minus data.
[F] : regards higher 4 bits of the memory as [-0]
[A] : regards higher 4 bits of the memory as [-1]
· range 1 word : -1999 ~ +9999
2 words : -19999999 ~ +99999999
<Ex.>
· How to set : Num. Display
[Input Type] BCD
[Display Type] DEC(w/ -sign, w/ +sign)
PLC memory Display of ZM-**
0000 ~ 9999 0 ~ 9999
F001 ~ F999 -1 ~ -999
A000 ~ A999 -1000 ~ -1999
00000000 ~ 99999999 0 ~ 99999999
F0000001 ~ F9999999 -1 ~ -9999999
A0000000 ~ A9999999 -10000000 ~ -19999999
