2 - 19

Available Memory

Memory Bit Write TYPE Remarks

D (data register) 0

W (link register) 1

R (file register) 2

TN (timer/current value) 3

CN (counter/current value) 4

SPU (special unit) 5 Unit No. *1

M (internal relay) 6

L (latch relay) 7

B (link relay) 8

X (input relay) 9

Y (output relay) 10

TS (timer/contact) 11

TC (timer/coil) 12

CS (counter/contact) 13

CC (counter/coil) 14

SD (special register) 16 only in Q mode

SM (special relay) 17 only in Q mode

SB (special link relay) 18 only in Q mode

SW (special link register) 19 only in Q mode

ZR 20 only in Q mode

(file register [continuous access])

*1 The unit number is required in addition to the memory type and the address.

Convert a byte address into a word address to enter the data if the memory device of link unit is

byte address.

Available: Unavailable:

Set the memory to the extent of the memory range of each PC model. In case of using the [Bit Write]

memory as the bit device of the [Output Action] is [Momentary W], the other bits will be cleared when the bit

memory is output, because the [Bit Write] will be output by one word (refer to P5-10, reference 14-7 of ZM-

71SE Instruction Manual). Use [TYPE] number to assign indirect memory for macro programs.

Wiring

RS-232C

Use the cable, [QCPU2](2, 3, 5, 10, 15m), made by Sharp Corporation.

2 MITSUBISHI PC • 3
