2 - 17
Wiring
Notes on using ZM-1MD2 (Dual Port Interface) (See page 1-60)
As the ZM-1MD2 is powered by a CPU, check that the electric capacity of the CPU is at 5V (power
consumption: max. 350mA).
The distance between the CPU and the ZM-1MD2 should be as short as possible (max. 1~1.5m).
For wiring, take appropriate measures to eliminate noise.
CPU
A6GPP, A7PHP, personal computer, etc.
In case of direct connection with the CPU port
of A/QnA series,plug the rear connector in the
CPU port, or use the exclusive cable(*).
* Exclusiue cable
(order product)
G
D
G
P
P
Slide switch
1 ----- A series
2 ----- QnA series
3 ----- FX series
* Set this switch before
power supply ON.
ZM-
**
12
3
MITSUBISHI A/QnA Series
RS-422
ZM-
**
(CN1)
PC
D-sub 25pin(Male: )
D-sub 25pin(Male: )
FG
SG
+SD
-SD
+RTS
-RTS
1
7
12
13
14
17
2
7
15
+RxD
SG
-RxD
16 -TxD
4 +DSR
17 -DSR
5 +DTR
18
20
-DTR
21
3 +TxD
-CTS
+CTS
+RD
-RD
18
19
24
25
Wiring Diagram 1
The following is a diagram to show the wiring of the cable which connects ZM-
**
to PC.
* Use twist shielded cables.
