Preparation before Use
2-50
NOTE: If using the machine with fax and the multi purpose tray is used to print a received FAX, the available media
types are as shown below.
Plain, Recycled, Bond, Color, High Quality, Rough, Labels, Envelope, Cardstock, and Thick
1 Press the System Menu/Counter key on the main unit
operation panel.
When you are performing user management and have
not logged in, a login screen will appear. Then, enter the
user ID and password to log in.
NOTE: Refer to Character Entry Method on Appendix-5 for
details on entering characters.
When you are not performing user management, go to
step 2.
2 In the Sys. Menu/Count. menu, press the U or V key to
select [Common Settings].
3 Press the OK key. The Common Settings menu appears.
4 Press the U or V key to select [Orig./Paper Set.].
5 Press the OK key. The Orig./Paper Set. menu appears.
6 Press the U or V key to select [MP Tray Set.].
7 Press the OK key. The MP Tray Set. menu appears.
8 Press the U or V key to select [MP Tray Size].
Login User Name:
L
b
********************
Login Password:
[ Login ]
Sys. Menu/Count.:
a
b
3
System
4
User/Job Account
*********************
5
Common Settings
Common Settings:
a
b
*********************
2
Default Screen
3
Sound
[ Exit ]
1
Language
Orig./Paper Set.:
a
b
*********************
2
Def. Orig. Size
3
Custom PaperSize
[ Exit ]
1
Custom Orig.Size
MP Tray Set.:
a
b
*********************
2
MP Tray Type
[ Exit ]
1
MP Tray Size
