Default Setting (System Menu)
Printer Settings
Printing from computers, settings are generally made on the application software screen. However, the following
settings are available for configuring the defaults to customize the machine.
• Emulation Set …8-75
• EcoPrint …8-78
• Override A4/LTR …8-79
• Duplex …8-80
• Copies …8-81
• Orientation …8-82
• FormFeed Timeout …8-83
• LF Action …8-83
• CR Action …8-84
• Paper Feed Mode…8-85
NOTE: If user login administration is enabled, you can only change the settings by logging in with administrator
privileges.
Emulation Set
Select the emulation for operating this machine by commands oriented to other types of printers.
Selection of emulation
This machine can emulate the following printers:
• Line Printer
• IBM Proprinter
• DIABLO 630
• EPSON LQ-850
•PCL6
•KPDL
• KPDL(Auto)
