Appendix-21
Scanner functions
*1
Available Operating System : Windows XP, Windows Server 2003, Windows Vista, Windows Server 2008, Windows 7
*2 Available Operating System : Windows Vista, Windows Server 2008, Windows 7
Document Processor
Item Description
Operating System Windows XP, Windows Server 2003, Windows Vista, Windows Server 2008,
Windows 7
System requirements IBM PC/AT compatible
CPU: Celeron 600Mhz or higher
RAM: 128MB or more
HDD free space: 20MB or more
Interface: Ethernet, USB
Resolution 600 dpi, 400 dpi, 300 dpi, 200 dpi, 200 × 400 dpi, 200 × 100 dpi
File Format JPEG,TIFF,PDF, XPS
Scanning Speed
*1
1-sided: B/W 35 Images/min
Color 14 Images/min
2-sided: B/W 18 Images/min
Color 8 Images/min
(A4 landscape, 300 dpi, Image quality: Text/Photo original)
Interface Ethernet (10 BASE-T/100 BASE-TX)
USB2.0 (Hi-Speed USB)
Network Protocol TCP/IP
Transmission
System
PC transmission SMB Scan to PC
FTP Scan to FTP, FTP over SSL
E-mail transmission SMTP Scan to E-mail
Scan to USB
TWAIN scan*
1
WIA scan*
2
Item Description
Original Feed
Method
Automatic feed
Supported Original
Types
Sheet originals
Paper Size Maximum: Legal/A4
Minimum: Statement/A5
Paper Weight Simplex: 50 to 120 g/m
2
Duplex: 50 to 110 g/m
2
Loading Capacity 50 sheets (50 to 80 g/m
2
) maximum
