Default Setting (System Menu)
Orig.Orientation
Set the original orientation defaults. The available default settings are shown below.
Refer to page 4-6 for Original Orientation.
Use the procedure below to select the default orientation when originals are placed on the platen.
1 In the Sys. Menu/Count. menu, press the U or V key to
select [Common Settings].
2 Press the OK key. The Common Settings menu appears.
3 Press the U or V key to select [Function Default].
4 Press the OK key. The Function Default menu appears.
5 Press the U or V key to select [Orig.Orientation].
6 Press the OK key. Orig.Orientation appears.
7 Press the U or V key to select [c Top Edge Top] or [d
Top Edge Left] .
8 Press the OK key. Completed. is displayed and the
screen returns to the Function Default menu.
Item Description
c Top Edge Top Select the original's top edge at the top.
d Top Edge Left Select the original's top edge at the left.
Sys. Menu/Count.:
a
b
3
System
4
User/Job Account
*********************
[ Exit ]
5
Common Settings
Common Settings:
a
b
*********************
2
Default Screen
3
Sound
[ Exit ]
1
Language
Function Default:
a
b
*********************
2
Scan Resolution
3
FAX Resolution
[ Exit ]
1
Color Selection
Orig.Orientation:
a
b
1
c
Top Edge Top
*********************
2
*
d
Top Edge Left
