8
8-109
Default Setting (System Menu)
Entering Group Name
1 Press the Y or Z key to display Group Name.
2 Press [Edit] (the Right Select key). An entry screen
appears.
3 Enter the group name.
If creating a new group name, the address number
allocated to the destination is already entered.
4 Press the OK key. The group name is registered.
Entering Group Member
1 Press the Y or Z key to display Group Member.
2 Press [Edit] (the Right Select key). This displays the list
of destinations registered to the group.
3 Press [Menu] (the Right Select key). The group editing
menu appears.
4 Press the U or V key to select [Add Member].
Detail:
C
b
Group Name: 1/4
Sales Section
[ Edit ]
Group Name:
A
b
Sales
*
S
ABC
[ Text ]
Detail:
C
b
Group Member: 2/3
30
[ Edit ]
Group Member:
a
b
*********************
Morgan
G
Morgan
[ Menu ]
p
Sally
Menu:
a
b
*********************
2
Delete
3
Add Member
1
Detail
