Teachable CareFree

Prolog:

The function CareFree helps the pilot to control the ARF-MikroKopter in a contact flight. It also helps if the Kopter is far

away and you cannot determine the front of the Kopter anymore.

On the ARF-MikroKopter the different colored rigger No. 1 is the „front“. If you control now the MikroKopter via the

transmitter the Kopter flies forwards if the „Nick“-Stick will be moved forwards. The Kopter flies backward if you move the

„Nick“-Stick backwards. Or sideways by moving the „Roll“-Stick.

It can be a little bit difficult if the ARF-MikroKopter will be turned during the flight with the „Yaw“-Stick. When turning the

Kopter necessarily rotates the front, too and you need to rethink controlling the Kopter.

Who has not that much practice in those situation and is inexperienced in a so called „flying nose“ can control the ARF-

MikroKopter easily wrong.

If, in example, the rigger No.1 points towards the pilot the Kopter will fly while moving the „Nick“-Stick forward – into the

direction of the pilot. The same is with the „Roll“-Stick. If you move the stick e.g. to the right, the Kopter moves left and

reverse.

The function:

The function (Teachable) CareFree can be activated / deactivated via the transmitter.

Example: The different colored rigger No.1 points away from the pilot.

If you enable now the function CareFree, it doesn't matter which direction

the front rigger points. With this enabled function you can turn the Kopter

during the flight as you like. If you move the „Nick“-Stick forwards the

Kopter flies away from the pilot all the time. Moving the „Nick“Stick

backwards, towards yourself, the Kopter flies to the pilot. It doesn't matter

in which direction the Kopter was turned.

(Assigned to a 2-way switch (ON/OFF) on the transmitter)

For an easier use of this function they are devided into two sections. Depending on whether the ARF MikroKopter is

inside or outside of a 20-meter radius around the starting point.

Function inside the 20-Meter radius around the starting point:

When the ARF-MikroKopter is inside of the 20-Meter radius around the starting point and always clearly visible,

determine the front of the Kopter (rigger No.1) after switching on the function CareFree.

Point the front of the Kopter e.g. away from the pilot and when the function CareFree is activated the Kopter will fly away

from the pilot and it doesn't matter where the front is if you move the „Nick“-Stick forwards.

If the function CareFree will be disabled and the Kopter is inside the 20mtr radius (e.g. by 90°) and the function

CareFree is enabled again, the new direction is the „front“. And it doesn't matter how the Kopter will be turned.

HiSystems GmbH Page 33
