REPLACING SUPPLIES AND MAINTENANCE
3
Take out the new toner cartridge, hold it with both
hands, and shake 5 or 6 times horizontally.
• When shaking the toner cartridge, be sure to shake with the protective
material inserted in the cartridge. If you shake the cartridge after
removing the protective material, toner may spill out.
• Shake the toner cartridge only in the horizontal direction. If shaken in
any other direction, toner may collect in one part of the cartridge.
4
Remove the protective material from the new toner
cartridge.
• Hold the toner cartridge firmly while removing the protective material.
• After the protective material has been removed, do not point the toner
cartridge down or shake it. Toner may spill out.
Protective
material
