47
REPLACING SUPPLIES AND MAINTENANCE
8
Clean the laser unit.
(1) Point the cleaner down and slowly insert the tool into
the hole that you wish to clean.
The parts of the writing unit that require cleaning are indicated by labels
similar to (A).
(2) Insert the cleaning tool all the way into the hole and
then pull it back out.
Pull the cleaning tool out until you feel the tip of the tool leave the
cleaning surface of the laser unit.
(3) Repeat step (2) two or three times and then remove the
cleaning tool.
(A)
mxc401_us_saf.book 47 ページ ２００８年１０月１５日 水曜日 午前１１時５２分
