9871 Tenth Edition A-5

Preparing Cartridges

Applying Cartridge Labels

Cartridge labels reflect the cartridge media and usage. Cleaning cartridges have

CLN in the VOLSER, while diagnostic cartridges have DG in the VOLSER. The

media ID label correlates to the tape drive or transport capable of using the

cartridge:

• Nonlabeled cartridges can be used for recording in the 4480, 4490 or 9490.

• A, B, and C labels are used for recording in the SD-3.

• D labeled cartridges are used in the SD-3 for cleaning.

• E labeled cartridges can be used for recording in the 4490 and 9490.

• P labeled cartridges are used for recording in the 9840.

• R labeled cartridges are used for recording in the T9940.

• U labeled cartridges are used in the 9840 for cleaning.

• W labeled cartridges are used in the T9940 for cleaning.

• Z labeled cartridges can be used for recording in the 9490.

Figure A-6. T9940 Cartridge Locations

C40890

CUSTOMER

AND

MANUFACTURER’S

LABEL

WRITE-PROTECT

SWITCH

LEADER

K -

VOLID AND

MEDIA LABELS

(MEDIA LABEL:

"P" = DATA,

"W" = CLEANING)

LEADER

BLOCK - OPEN
