Preparing Cartridges

A-12 Tenth Edition 9871

Setting the SD-3 Write Protect Switch

You can set the write protect switch so that the cartridge is read-only (nothing

can be written on the tape). Slide the switch to the right so that the pencil icon

is split as shown in Figure A-16. In this position, the drive can only read data

from the tape and can not write data.

You can set the write protect switch so that the SD-3 cartridge is write enabled.

Slide the switch to the left so that the pencil icon is joined as shown in

Figure A-16. In this position, the drive can write as well as read data. This

setting is recommended when entering cartridges into the LSM.

Note: Some software has a feature called virtual thumbwheel, allowing read-

only access to a cartridge that is not physically write protected.

Figure A-16. SD-3 Cartridge Write Protect Switch

0867

LABELS

LEADER

BLOCK

DETENT

SPRINGS

WRITE ENABLE POSITION

WRITE PROTECT POSITION
