Model G2-0402

G2-0402 model uses 0.4 MPx Kodak KAF-0402ME Class 1 or 2 CCD chip.

Resolution

768×512 pixels

Pixel size

9×9 µm

Imaging area

6.9×4.6 mm

Full well capacity Approx. 100 000 e-

Output node capacity Approx. 220 000 e-

Dark current 1 e-/s/pixel at 0°C

Dark signal doubling 6.3 °C

Model G2-1600

G2-1600 model uses 1.6 MPx Kodak KAF-1603ME Class 1 or 2 CCD chip.

Resolution

1536×1024 pixels

Pixel size

9×9 µm

Imaging area

13.8×9.2 mm

Full well capacity Approx. 100 000 e-

Illustration 4: Temný proud CCD čipů Kodak používaných v kamerách série G2
