Panel Management and Option

●Controlling a panel manually

SetthisoptionwhenyouwanttocontrolthetargetPCmanually.

 WhencontrollingthetargetPCmanually,(whenturningonthepanelPC),theWakeOnLANfunction

thatoperatesbyMagicPacketssentfromthetargetPCmustbeenabled.

IfthetargetPCisoutsidethesameLANsegment,MagicPacketsmaynotgetthroughdependingon

routerspecsandsettings.Contactyournetworkadministratorformoredetails.

1. Click [Manual Control].

The[ManualControlforthePanel(PanelPC)]dialogboxwillappear.

2. Check the check boxes next to the panels or groups that

you want to control.

Selecta“ControlCommand”.

The following three control commands can be sent:

•PCPowerON

•PCReboot

•PCPowerOFF

3. Click [Execute].

The control command will be sent.

●Deleting a panel or group

1. Select the panel or group that you want to delete.

If you select a group, all the panels assigned to that

group will be deleted.

2. Click [Delete].

Aconﬁrmationdialogboxwillappear.

3. Click [OK].

Managing panels
