112

Status Monitoring Tool

Acquiring and displaying panel status

●Acquiring status of selected panels

1. Select a group from the group tree, and then select a

panel from the panel list.

 •Toselectallpanelsinthepanellist,eitherclick

[Selectallpanels]fromthe[Panel]menu,orpress

[Ctrl]+[A].

•Toselectallpanelsinthepanellistthatarenotresponding

(including panels for which status has not

beenacquired)

,eitherclick[Selectpanelswithoutresponse]fromthe[Panel]menu,orpress[Ctrl]

+[Shift]+[A].

•Toselectallpanelsinthepanellistthatareresponding,eitherclick[Selectpanelswithresponse]

fromthe[Panel]menu,orpress[Ctrl]+[Alt]+[A].

2. From the [Panel] menu, click [Status acquisition of selected panels].

Statusacquisitionofselectedpanelswillstart.

 •ToacquirepanelstatusforallpanelsregisteredinPanelManagement(exceptforpanelsset

withoutstatusacquisition),click[Startofstatusacquisition]fromthe[Option]menu,oralternatively,

click

•Tocancelpanelstatusacquisition,click[Cancelofstatusacquisition]fromthe[Option]menu,or

alternatively, click

Whenpanelstatusisacquired,paneliconsandthumbnails

will change.

The image can be enlarged by double-clicking it.
