Timetable Editor

SetprogramscreatedwithProgramEditortodisplayatasethouroftheday.

The main Timetable Editor window

●Launching Timetable Editor

1. Click on the Launcher window.

“TimetableEditor”willlaunch.

WhenTimetableEditorlaunches,anewblanktimetablewithnoprogramsassignedwillbedisplayed.

Timetables are completed after program is set on this screen.

 TimetableEditorcanalsobelaunchedbygoingtotheWindowsTaskbarandclicking[Start],

[AllPrograms],[SHARPDigitalSignageSoftware],[Tools],andthen[TimetableEditor].

●The main Timetable Editor window

1)Titlebar

2)Menus

3) Toolbar

4)Tabs

5)Program/Panel

Controllist

6)Timetable

1) Title bar

The name of the timetable will be displayed here.

WhenTimetableEditorlaunches,thetitlebarwillread“Untitled”.Whenatimetableissaved,itwillchangeto

the name of the timetable. When content of an opened timetable is changed, the title bar will display an asterisk

(*) after the timetable name.

Creating/Editing a Timetable
