PART NAMES AND FUNCTIONS
1-5
1
Interior
Fusing unit
Toner images are fused here.
Toner cartridge
The toner cartridge must be replaced when
indicated on the operation panel. (See page 2-15)
Right side cover
Open when a misfeed has occurred in the paper
feed area.
Right cover of paper drawer
Open this cover to remove paper misfed in the
paper drawer.
CAUTION
The fusing unit is hot. Take care in removing misfed
paper.
ApollonII_general-copy_SEC.book 5 ページ ２００４年９月６日 月曜日 午後４時５７分
