Chapter 4 How to Use the Operator Panel
Appendix
Glossary
Introduction
Index
Contents
TOP
70
How to Load
Documents
How to Use the
Operator Panel
Various Ways to
Scan
Daily Care
Troubleshooting
Operational
Settings
Replacing the
Consumables
Scanner
Overview
Configuring the
Scan Settings
■Checking the guidance contents
1 Press the [Power] button on the operator panel.
The [Ready] screen is displayed on the LCD.
2 Press the [Menu] button.
The [Settings Menu] screen is displayed on the LCD.
3 Press the [] or [] button and select [Guidance], then
press the [Scan/Enter] button to confirm.
The [Guidance] screen is displayed on the LCD.
4 Press the [] or [] button and select [1: Clear counter],
then press the [Scan/Enter] button to confirm.
The [Clear counter] screen is displayed on the LCD.
5 Press the [] or [] button to check the contents of the
guidance.
You can check the way to reset the page counter.
M
e
nu
Scan/Enter
C
heck
Power
Stop/Clear
2 [Menu] button
3 []/[] button
[Scan/Enter] button
5 []/[] button
1 [Power] button
4 []/[] button
[Scan/Enter] button
