2 Slide out the stacker extension 1 towards you. 3 Slide out the stacker extension 2 towards you.
Stacker extension 1
HINT
For A4 size documents, slide out the stacker extension 2 towards
you to click in place.
For legal size documents, slide out the stacker extension 2 towards
you all the way.
Stacker extension 2
