Removalstepsofthesystemboardassembly
ForThinkPadEdge15"andE50:
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2×5mm,wafer-head,nylon-coated(4)
Black0.181Nm
(1.85kgf-cm)
ForThinkPadEdge14"andE40:
1
1
StepScrew(quantity)Color
Torque
1
M2×5mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
