Removalstepsofthememorymodule
1
1
2
Note:Ifonlyonememorymoduleisusedonthecomputeryouareservicing,thecardmustbeinstalledin
SLOT-0(a:lowerslot),butnotinSLOT-1(b:upperslot).
b
a
Wheninstalling:Insertthenotchedendofthememorymoduleintothesocket.Pressthememorymodule
rmly,andpivotituntilitsnapsintotheplace.Makesurethatitisrmlyxedintheslotanddoesnot
moveeasily.
1060Fanassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1030Thermalcover”onpage59
Attention:
•Donothandlethefanroughly.Improperhandlingofthefancancausedistortionordeformationand
imperfectcontactwithcomponents.
•Donottouchorapplyanyexcessiveforcetothefanmotor.Itmightcausedamagetothefanassemblyor
thecomputertomulfunction.
62HardwareMaintenanceManual
