Volume Adjustment
33
1. Installation
Volume Adjustment
You can adjust the volume of the speaker and ringer using the
UP
and
DOWN
keys.
2
Press the
UP
or
DOWN
key.
3
When the display shows the desired
volume level, press the
SPEAKER
key to turn off the speaker.
SPEAKER: HIGH
Display:
SPEAKER: MIDDLE
SPEAKER: LOW
or
Handset
1
Lift the handset.
Speaker
1
Press the
SPEAKER
key.
DOWN
key
UP
key
SPEAKER
SPEAKER
DOWN
UP
2
1
3
9
4
5 6
7
8
0
all-ux340L.book Page 33 Thursday, December 23, 1999 5:37 PM
