Polling (Requesting a Fax Transmission)
112
1
Dial the fax machine you want to poll
using one of the following methods:
•
Pick up the handset (or press the
SPEAKER
key) and dial the full
number. Wait for the fax
answerback tone.
•
Press the
SPEED DIAL
key and
enter a 2-digit Speed Dial number.
•
Enter the full number using the
numeric keys.
2
Press Rapid Key 04/POLL.
•
If you used the handset, replace it
when POLLING appears in the
display. Reception will begin.
(Example)
2
5
8
GHI
JKL
MNO
TUV
WXYZ
PQRS
ABC
DEF
1
4
7
3
6
9
Requesting transmission
Note: Rapid Dial Keys cannot be used for polling. To dial a Rapid Dial
location, press the SPEED DIAL key and then enter the 2-digit number
corresponding to the Rapid Key.
04/POLL
all-ux340L.book Page 112 Thursday, December 23, 1999 5:37 PM
