Maintenance

8. Maintenance

4 Place the imaging film back in the print

compartment.

5 Rotate the front gear until the film is taut, and then close the operation

panel (press down on both sides to make sure it clicks into place).

Scanning glass and rollers

Clean the scanning glass and rollers frequently to ensure the quality of

transmitted images and copies.

Note: Remove the paper from the paper tray before cleaning the scanning

glass and rollers.

1 Open the operation panel (press ➊).

all.bookPage81Thursday,November15,20014:31PM
