Using TEL Mode
62
1 When the fax machine rings, pick up
the handset.
2 If you hear a fax tone, wait until the
display shows RECEIVING and then
replace the handset.
3 If the other party first speaks with you
and then wants to send a fax, press
after speaking. (Press before
the sender presses their Start key.)
• When RECEIVING appears in the
display, hang up.
START/MEMORY
Answering on an extension phone
Answering with the fax’s handset
Note: If you have set the Fax Signal Receive setting
(page 63) to NO, press to begin reception.
START/MEMORY
Beep
START/MEMORY
1 Answer the extension phone when it
rings.
RECEIVING
RECEIVING
all.bookPage62Thursday,November15,20014:31PM
