MISFEED REMOVAL

COPIER TROUBLE?

Remove the misfed paper.

●

Be careful not to tear the misfed paper during removal.

If the misfed paper is not seen in step 2, pull out the lower paper tray

and remove the misfed paper.

●

Be careful not to tear the misfed paper during removal.

Close the paper tray.

Close the lower side cover.

●

Confirm that the misfeed display has been cleared.

Misfeed in the upper exit area

If an optional job separator tray kit or an optional finisher is installed, a misfeed may occur in the upper

exit area.

Open the upper exit area cover.
