GETTING STARTED
FUNCTION REVIEW
The current settings of copier functions that have been selected can be viewed in the display.
●
The XY ZOOM and TRANSPARENCY functions cannot be viewed on the function review screen.
1
Press the JOB STATUS key.
●
The review screen will appear.
2
Use the and keys to select a function.
●
The setting for the selected function will appear in the display.
●
The settings of the duplex copy mode (1-sided to 1-sided, etc.), sort/group mode, and
special functions can be displayed. Exposure, paper size, and copy ratio settings which
are normally displayed on the basic screen cannot be displayed on the review screen.
3
To exit the review screen, press the BACK key.
●
The display will return to the basic screen.
2in1
PATTERN1
NO
FUNCTION REVIEW
8
11
1
2
/
Ready to copy.
8
11
1
2
/
100%
100%
AUTO
AUTO
00.book 19 ページ ２００１年４月２０日 金曜日 午後９時３４分
