EXPOSURE ADJUSTMENT

MAKING COPIES

Use the and keys to adjust the copy density as desired.

●

Copy density cannot be adjusted manually in the AUTO exposure mode.

Press the OK key.

●

To return to the AUTO mode, press the EXPOSURE key, use the and key to select

"AUTO", and press the OK key.

NOTE:

When the SUPER PHOTO mode is selected, the copy ratio is limited to be within the 50% to

200% range when copying from the platen glass and within the 50% to 141% range when using

an optional SPF or RSPF.

EXPOSURE

AUTO

TEXT/PHOTO

AUTO

TEXT

00.book 30 ページ２００１年４月２０日金曜日午後９時３４分
