(2) Print setup of data list -> See page 9-1 and 9-11

If you click [Print Setup] on the [File] menu (see No.10/16.), the [Print Setup] dialog box will appear.

Content

Setup Items

①

②

③

Allows you to choose "Attach" or "None" for printing header on each page. If you

choose "Attach" to print header, you need to specify a file name. ※

Allows you to choose "Attach" or "None" for printing footer on each page. If you

choose "Attach" to print footer, you need to specify a file name. ※

Print of Symbol

Print of Comment

Margins

Allows you to set up the print of symbol/comment (Print/No Print).

Allows you to set up margins (Provide margins/No margins) on left side or upper side.

Header

Footer

Boot HF Editor

Allows you to start up [HF Editor] that creates a title, header, and footer.

※ You can specify a file name on the [Select File] dialog box by clicking [Reference] (see num-

ber ① above) at title/header/footer columns. (Same as on pages 9-3 and 9-4.)

The files for title/header/footer can be created by clicking [Boot HF Editor] (see number ②

above). -> See [9-2 HF Editor].

If you click on [OK] (see number ③ above) after you finished the setup of each item, the setup data will

be registered.

Title

Allows you to choose "Attach" or "None" for printing a title. If you choose "Attach"

to print a title, you need to specify a file name. ※

Print Type

Allows you to specify an address area to be printed.

No.12/16
