PAPER
88
GENERAL INFORMATION
Changing the copy paper size in the tray
Paper size setting can only be done while the machine is not operating and the COPY mode has been
selected.
●
B5 paper cannot be set for paper tray 2.
1
Press the SPECIAL FUNCTION key.
●
The SPECIAL FUNCTION screen will appear.
2
Use the and keys to select "PAPER SIZE SET" and press the OK
key.
●
The paper size setting screen will appear.
3
Use the and keys to select the paper tray for which the paper size
is being changed.
4
Press the key.
SPECIAL FUNCTION
SPECIAL MODES
ORIG. SIZE ENTER
PAPER SIZE SET
DISPLAY CONTRAST
PAPER SIZE SET
8
11
1
2
/
11 17
11 17
8
14
8
13
8
11
1
1
1
2
2
2
/
/
/
PAPER SIZE SET
2
8
11
1
2
/
11 17
11 17
8
14
8
13
8
11
1
1
1
2
2
2
/
/
/
