Sending a Fax by Automatic Dialing
45
2. Sending
Documents
Rapid Key Dialing
If the number you want to dial has been programmed in a Rapid Key, you can
dial it by pressing the Rapid Key.
1 Load the document(s).
SEND READY will appear in the
display.
• Press and/or to
set the resolution and contrast if
needed.
• To send the document ahead of other
documents waiting for transmission,
press .
• To send the document directly from the
feeder (not through memory), press
. (Flip up the Rapid Key overlay
if it is down.)
2 Press the appropriate Rapid Key.
• The name of the receiving party will appear in the display. If no name was
stored, the fax number will appear. (If the name or number is incorrect,
press .)
• The document will be automatically transmitted once the connection is
established.
RESOLUTION
CONTRAST
PRIORITY
DOCUMENT
M/?
STOP
