Sending a Fax by Automatic Dialing
51
2. Sending
Documents
Speed Dialing
If the number you want to dial has been programmed in a Speed Dial
number, you can dial it by pressing the SPEED DIAL key and then
entering the Speed Dial number.
1
Load the document(s).
SEND READY will appear in the
display.
• Set the resolution and/or contrast if
desired.
• To send the document ahead of
other documents waiting for
transmission, press the PRIORITY
key.
• To send the document directly from
the feeder (not through memory),
press the DOCUMENT key.
2
Press the SPEED DIAL key and then
enter the Speed Dial number by
pressing the numeric keys.
• If you enter less than 2 digits for the
Speed Dial number on the FO-
4650, or 3 digits on the FO-4970,
press the START key to complete
the entry.
Example: Speed Dial 1
1
SPEED DIAL
RESOLUTION
Q
CONTRAST
DOCUMENT
PRIORITY
START
all-FO4700.book Page 51 Tuesday, November 28, 2000 2:07 PM
