SADDLE STITCH FINISHER
3-14
Relation between print image and saddle stitch
The orientation of the copy paper, original, scanned original data, and binding position selection are all interrelated.
The table below shows these relationships.
Same as above
Orientation of original or original data
Output result
Page 1
Page 3
Page 2
Page 4
Page 1 & Page 2
Duplexed
Page 3 & Page 4
Duplexed
Right bindingLeft binding
Portrait orientation printing
Page 1
Page 3
Page 2
Page 4
Page 1 & Page 2
Duplexed
Page 3 & Page 4
Duplexed
Left binding Right binding
Landscape orientation printing
Same as above
WhaleII_general-copy_SEC.book 14 ページ ２００４年９月１４日 火曜日 午前１１時４５分
