7-7
Label (orange)
Shutter (orange)
4
Holding the new toner cartridge as shown on the
right, pull out the seal in the direction of the arrow.
5
Match the label(orange) on the copier with the
shutter(orange) on the toner cartridge, then insert
the toner cartridge to the end.
- If you cannot insert the toner cartridge completely, rotate it
slightly to check the position and insert it again.
- If the toner scatters, wipe it off completely.
6
Return the toner cartridge holder back to its original
position.
7
Close the front cover.
- The following message appears:
Wait adding toner
The copier automatically starts supplying toner.
- When toner has finished being supplied, the touch panel
returns to the basic menu and the current job automatically
resumes.
