LOADING PAPER

Special papers

Follow these guidelines when using special papers.

● Use SHARP recommended transparency film and label sheets. Using other

than SHARP recommended paper may result in misfeeds or smudges on

the output. If other than SHARP recommended media must be used, feed

each sheet one at a time using the bypass tray (do not attempt continuous

copying or printing).

● There are many varieties of special paper available on the market, and

some cannot be used with this machine. Before using special paper,

contact your authorised service representative.

● Before using other than SHARP recommended paper, make a test copy to

see if the paper is suitable.

LOADING THE PAPER TRAY

Raise the handle of the paper tray

and pull the paper tray out until it

stops.

Fan the paper and insert it into the tray. Make sure that the

edges go under the corner hooks.

Make sure that the paper is not torn, is free of dust, and has no wrinkles

or curled edges.

• Do not load paper above the maximum height line ( ).

Exceeding the line will cause a paper misfeed.

• If the paper is not fanned, double-feeds or misfeeds may occur.

• Make sure the stack of paper is straight before loading it. When

adding paper, take the remaining paper out and combine it into a

single stack with the new paper.

• Make sure that all the paper in the stack is the same size and type.

• When loading paper, ensure that there is no space between the

paper and the guide, and make sure that the guide is not set too

narrow and causes the paper to bend. Incorrect loading will cause the

paper to skew or misfeed.
