SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, NJ 07495-1163

1-800-BE-SHARP • www.sharpusa.com

Some features may require optional equipment.

Specification may vary depending on product configuration,

machine settings and operating conditions.

Color

Consistency

System

mX-6500n/7500n sPeciFicAtions

Main Specifications

MX-6500N/ Base models include, 150-sheet DSPF, 3,000-sheet paper

MX-7500N capacity, 1-TB hard disk drive, PCL6/Adobe

PostScript

network printing, color network scanning, web browser and

swing-out keyboard. Includes Application Communication

Module and External Accounting Module.

Type Light production, color multi-function digital document system

Display 15.4" (diagonally measured) color dot matrix high-resolution

touch panel tilting display. 1280 x 800 dots (WXGA)

Functions Copy, print, network print, network scan and document filing

Copy System Dry electrostatic transfer/Dual component developer/Magnetic

brush development/OPC/Belt fusing/white LED exposure

Original Size Max. 11" x 17" sheets and bound documents

Copy Size Min. 5½" x 8½" (paper), Max. 13" x 19" (paper)

Printable Area Max. 13" x 19"

Copy Speed 65/75 ppm B&W/Color (8½" x 11")

Multiple Copy Max. 9999 copies

First Copy Time MX-6500N MX-7500N

(in Seconds)

B&W Color B&W Color

Platen Glass 4.0 5.6 3.7 5.1

DSPF 6.5 9.2 6.3 8.8

Warm Up Time 90 seconds

Magnification 25% to 400% in 1% increments (with DSPF 25%-200%)

Original Feed 150-sheet DSPF

Scan Speed DSPF Scan: Up to 150 IPM

(Monochrome); Up to 150 IPM

(Color)

Original Sizes 5½ x 8½", 8½" x 11", 8½" x 11" R, 8½" x 14", 11" x 17"

Paper Capacity Std. 3,000 sheets/max. 13,500 sheets

Paper Feed Standard: Tandem Tray 1 - 1200 sheets (letter size), Tandem

Sizes

Tray 2 - 800 sheets (letter size), Trays 3/4 - 500 sheets ea.

(letter/legal/ledger/statement/12" x 18"). Optional: Bypass

Tray (for machine) - 100 sheets (letter/legal/ ledger/statement/

envelope/12" x 18", 13" x 19"), banner paper up to 12" x 47.2",

Bypass (for LCT) - 500 sheets (letter/legal/ ledger/statement/

12" x 18", 13" x 19"), LCT (2-Drawer) - 2,500-sheets each

drawer (letter/legal/ledger/12" x 18", 13" x 19"), Letter

LCC - 3,500 sheets (letter), Ledger LCC: 3,000 sheets

(letter/legal/ ledger, 12" x 18", 13" x 19").

Paper Weights Tandem Trays - 16-28 lb. bond (60-105 gsm), Trays 3/4 - 16 lb.

and Types bond to 100 lb. bristol (60-220 gsm), Multi-bypass Tray

(for machine) - 15 lb. bond to 110 lb. cover (55-300 gsm),

Multi-bypass Tray (for LCT) - 15 lb. bond to 100 lb. bristol

(55-220 gsm), LCT (2-drawer) - 15 lb. bond to 110 lb. cover

(55-300 gsm), Letter/Ledger LCC - 16 lb. bond to 100 bristol

(60-220 gsm). Includes thin, plain, recycled, color, letter head,

pre-printed and pre-punched, embossed and glossy paper.

Duplexing Standard, supports up to 110 lb. cover (300 gsm)

CPU Multi-Processor Controller

Interface RJ-45 Ethernet (10/100/1000Base-T), USB 2.0 (2 host ports,

front and rear), USB 2.0 (1 device port)

Memory Standard 5 GB

Hard Disk Drive 1 TB

Copy Resolution B&W: 1200 x 1200 dpi (max.), Color: 600 x 600 dpi (max.)

Color Modes Photo, Full Color Mode, Monochrome (B/W)

Exposure Control Modes: Text, Text/Photo, Text/Printed-Photo, Printed-Photo,

Photo, Map, Pale-Color . Settings: Auto or 9 step manual

Halftone 256 gradations/2 levels (monochrome)

Copy Features Electronic sort, Auto Color Sensing, Auto Paper Selection, Auto

Magnification Selection (AMS), image preview/edit, auto tray

switching, rotate copy, reserve copy, tandem copy, book copy,

margin shift, edge/center erase, book divide, dual page, cover/

insert page, OHP insert, job build, card shot, blank page skip,

mirror/reverse, proof, watermark, custom image, job programs.

Account Control Up to 1000 users. Supports user-number authentication (on

device), login name/password or login name/password (via LDAP

server) for Copy, Print, Scan, Fax and document management.

Output Capacity Main output tray (top) 250 sheets (face down)

Firmware Flash ROM (USB), network update capability and 1 to N update

Management with SRDM (Sharp Remote Device Management)

Configuration Web-based management with user/administrator level login,

Method cloning (1 to N) with SRDM and remote front panel access

Service/Functions Remote front panel, access to service logs and click counts

Accessibility Tilt Front Panel, Adjustment of Key Touch-Send and Speed,

Features Document Feeder Free Stop, Job Programs, Remote Front Panel,

Universal Grip for Paper Trays, and Disable Screen Timeout

Environmental International Energy Star Program Ver. 1.2, Law on Promoting

Standards Green Purchasing. European RoHS

Pwr. Source AC 208-240 VAC, 60 Hz, 20 Amps

Pwr. Consumption Maximum: 2880w or less

Weight MX-6500N/7500N: Approx. 503 lbs.

Dimensions Approx. 33 1/4" (w) x 33 1/4" (d) x 48" (h)

Network Printing System (Standard)

PDL Standard PCL

6 compatible Adobe

, PostScript

, optional XPS

Resolution 1200 x 1200 dpi/8-bit processing

Print Speed 65/ 75 pages per minute (8½" x 11")

Print Drivers Windows Server

2003-2008, Windows XP, Windows XP x64,

Windows Server 2003-2008 x64, Windows Vista

, Windows

Vista

x64, Windows 7, Windows 7 x64, Windows 8, Windows

8 x64, MAC OSX (including 10.4, 10.5, 10.6, 10.7), all MAC PPD.

Features Auto configuration, continuous printing, edge to edge printing,

electronic sorting, N-up printing, duplex printing, transparency

inserts, margin shift, image rotation, different cover page,

poster print, job bypass print, job retention, confidential print,

proof print, user authentication, image stamp and watermarks.

Additional features: Multiple pamphlet print, network tandem

print, carbon copy print mode, different cover page/last page/

other page, form overlay, tab paper settings, tab printing,

chapter inserts and page Interleave

Direct Printing File Types: TIFF, JPEG, PCL, PRN, TXT, PDF, Encrypted PDF,

PostScript and Windows XPS

(FTP, Web page, E-mail and USB)

Resident Fonts 80 outline fonts (PCL), 136 fonts (PS)

Interface RJ-45 Ethernet 10/100/1000 Base-T, USB 2.0

Operating Windows Server 2003-2012, Windows XP, Windows Vista,

Systems Windows 7, Windows 8, MAC OS X10.4, X10.5, X10.6, X10.7,

X10.8, Novell

Netware

Unix

, Linux

and Citrix

(XenApp 5.0

6.0, 6.5) and Windows Terminal Services, SAP device types.

Network TCP/IP (IPv4, IPv6, IPSEC) SSL (HTTP, IPP, FTP), SNMPv3, SMTP,

Protocols POP3, LDAP, 802.1x for Windows and Unix. LPD and LPR for

Unix. IPX/SPX

for Novell environments. EtherTalk

, AppleTalk

for Macintosh

environments.

Printing Protocols LPR, IPP, IPPS, PAP, Raw TCP (port 9100), FTP and Novell

Pserver/Rprinter

Network Security IP/MAC address filtering, protocol filtering, port management,

user authentication and document administration.

Security Stds. IEEE-2600

-2008, DoD (NSTISSP) #11, CAC/PIV access control

Network Scanning System (Standard)

Scan Modes Standard: Color, monochrome, grayscale

Original Size 11" x 17" (Max.)

Resolution 600 dpi

Output Modes 600 dpi, 400 dpi, 300 dpi, 200 dpi, 150 dpi, 100 dpi

Image Formats Monochrome: TIFF, PDF, PDF/A, Encrypted PDF, Compact PDF,

XPS; Color: Grayscale, Color TIFF, JPEG, PDF, Encrypted PDF, XPS

Image Monochrome Scanning: Uncompressed, G3 (MH), G4 (MR/MMR)

Compression Color/Grayscale: JPEG (high, middle, low), Compact PDF

Scan Dest. E-mail, FTP, Folder (SMB), USB

One-touch Dest. Up to 2000 (combined scan destinations)

Group Dest. Up to 500

Programs 48 (combined)

Max. Jobs Up to 100

Protocols TCP/IP and SSL (includes HTTP, SMTP, LDAP, FTP, POP3), SMB,

ESMTP and 802.1x.

Network Security E-mail server user authentication for LDAP and Active Directory

Fiery Color Print Server (Option)

Server Type External Server

System Software Fiery FS100 Pro

CPU Type Intel

Core

i5-2400

CPU Speed 3.1 GHz

Memory 4 GB RAM

Hard Disk Drive 1 TB

Operating System Windows 7 Professional for Embedded Systems x32/x64

Network Conn. RJ45 10/100/1000 Base-T

Pwr. Source 100-240 VAC, 50/60 Hz, 6A

Pwr. Consumption 125w (Typical)/350w (Max.)

Dimensions Approx. 8 1/2" (w) x 14" (d) x 19 1/4" (h)

Weight Approx. 43 lbs.

Options Fiery Color Profiler Suite, Fiery Graphic Arts Package Premium

Edition, Fiery JobMaster

, Fiery Impose, Fiery Compose, Fiery

JobFlow

, Fiery Impose-Compose, Fiery JobMaster-Impose, EFI

ES-2000 Spectrophotometer, Fiery Central, Removable Hard Disk

and FACI Kit (Fiery Integrated Workstation)

Inserter (Option)

Paper Capacity Upper Tray: 200 sheets; Lower Tray: 200 sheets (20 lb. bond)

Paper Weight 16 lb. bond to 100 lb. Bristol (Paper feeding)

Paper Size Up to 13" x 19"

Power Cons. 70w or Less

Power Source 24 Volts (Supplied by Main Unit)

Dimensions 21 1/2" (w) x 30" (d) x 50 1/2" (h)

Weight Approx. 51 lbs.

4K 100-Sheet Stapler/Finisher (Option)

Type 4,000-sheet console stapler finisher (100-sheet stapling)

Output Trays Upper tray: Moving offset tray (up to 1,500 letter size sheets)

Middle tray: 250 sheets (letter size, non-stapled)

Lower tray: Moving offset tray (up to 2,450 letter size sheets)

Staple Capacity Up to 100 sheets (letter/statement)

Staple Media Plain paper, letter/legal/ledger size or mixed

Staple Positions 1 front, 1 rear, or 2 point stitching

Pwr. Source 120 VAC, 60 Hz, 15 Amps

Pwr. Consumption 200w/350w with MX-FD10

Weight Approx.: 134.5 lbs.

Dimensions Approx.: 30 3/4" (w) x 30" (d) x 41" (h) (with tray extended)

4K 100-Sheet Stapler/Saddle Stitch Finisher (Option)

Type 4,000-sheet console saddle-stitch finisher

(100-sheet stapling)

Output Trays Upper tray: Moving offset tray (up to 1,500 letter size sheets)

Middle tray: 250 sheets (letter size, non-stapled)

Lower tray: Moving offset tray (up to 2450 letter size sheets)

Staple Capacity Up to 100 sheets (letter/statement)

Staple Media Plain paper, letter/legal/ledger size or mixed

Staple Positions 1 front, 1 rear, or 2 point stitching

Saddle Stitch Center stitch/center fold (2 staples)

letter/legal/ledger sizes

Saddle Stitch Up to 5 sets (16-20 sheets)/10 sets (11-15 sheets per set)/15

Max. Sets sets (6-10 sheets per set)/25 sets (1-5 sheets per set)

Pwr. Source 120 VAC, 60 Hz, 15 Amps

Pwr. Consumption 200w/350w with MX-FD10

Weight Approx.: 134.5 lbs.

Dimensions Approx.: 30 3/4" (w) x 30" (d) x 41" (h) (with tray extended)

Optional Equipment

MX-LC12 3,500-sheet Large Capacity Cassette (letter)

MX-LC13 5,000-sheet Large Capacity 2-Drawer Air-Feed Tray (ledger)

MX-LCX3N 3,000-sheet Large Capacity Cassette (ledger)

MX-MF10 100-sheet Multi-bypass Tray (for machine)

MX-MF11 500-sheet Multi-bypass Tray (for MX-LC13)

MX-LT10 Long Paper Feeding Tray (requires MX-MF10)

MX-FN21 4K Stacking 100-sheet Staple Finisher

MX-FN22 4K Stacking 100-sheet Staple/Saddle Stitch Finisher

MX-CF11 2-Tray Inserter Unit

MX-FD10 Multi-folding Unit

MX-ST10 5,000-sheet Stacker (includes paper cart)

MX-CA10 Paper Cart (additional)

MX-RB12 Paper Pass Unit (for machine)

MX-RB13 Relay Unit

MX-RB14 Paper Pass Unit (for MX-LC13)

MX-RB15 Curl Correction Unit

MX-RB17 Large Capacity Tray Tandem Connecting Kit

MX-TM10 Trimmer Unit

MX-PN13B 3-Hole Punch Unit (for MX-FN21/FN22)

MX-SCX1 Staple Cartridge (for MX-FN22)

MX-SCX2 Staple Cartridge (for MX-FN21/FN22)

MX-TR14 Right Side Exit Tray

MX-TU14 Center Exit Tray

AR-SU1 Stamp Unit (requires AR-SV1 Stamp Cartridge)

AR-SV1 Stamp Cartridge (required for AR-SU1)

MX-PF10 Bar Code Font Kit

MX-PUX1 XPS Expansion Kit

MX-EB11 Compact PDF Kit

MX-PE10 Fiery Color Print Server

MX-PX10 Fiery Interface Kit

MX-EB15 HDD Mirroring Expansion Kit

MX-EC50 CAC Reader (requires Data Security Kit)

MX-BM50 Plockmatic Booklet Maker

MX-GBCX2 GBC SmartPunch Pro

MX-FR43U Commercial Data Security Kit (not available at time of launch)

MX-AMX1 Application Integration Module

MX-SL10N Status Indicator

DVENDPS Generic Vend Interface Kit

Supplies

MX-62NTBA Black Toner Cartridge

MX-75NTCA Cyan Toner Cartridge

MX-75NTMA Magenta Toner Cartridge

MX-75NTYA Yellow Toner Cartridge

MX-62NVBA Black Developer

MX-62NVSA Cyan/Magenta/Yellow Developer

MX-62NRSA Drum

MX-700HB Toner Collection Container

Design and specifications subject to change without notice. Sharp, Sharp OSA and

all related trademarks are trademarks or registered trademarks of Sharp Corporation

and/or its affiliated companies. Windows, Windows Server and Windows Vista are

trademarks or registered trademarks of Microsoft Corporation. EFI, Fiery, Electronics

For Imaging, the Fiery logo, the EFI logo, FreeForm, Spot-On, WebTools and Command

WorkStation are trademarks or registered trademarks of Electronics For Imaging, Inc.

All other trademarks are the property of their respective owner.

1 2

MX-6500N MX-7500N 1
Consistency 2

Comentarios a estos manuales

Sin comentarios

Sharp MX-7500N Manual de usuario Pagina 2

Comentarios a estos manuales

Relacionado con productos y manuales para Multifuncionales Sharp MX-7500N
