Copier trouble?

MISFEED REMOVAL

●

Do not touch the surface of the drum (green portion) of the drum cartridge

when removing the misfed paper. Doing so may cause smudges on copies.

●

Do not remove the misfed paper from above the fusing unit. Unfixed toner on

the paper may stain the paper transport area, resulting in smudges on copies.

Raise the fusing unit release lever and then close the side cover by pressing the

round projections near the side cover open button. The misfeed ( ) indicator will go

out and the ready ( ) indicator will light up.

C Misfeed in the transport area

Lower the fusing unit release lever.

Fusing unit release lever

Push gently on both sides of the front cover to open the cover.
