1. Installation
Unpacking Checklist
Before setting up, make sure you have all of the following items. If any are
missing, contact your dealer or retailer.
Points to keep in mind when setting up
Do not place the
machine in direct
sunlight.
Do not place the
machine near
heaters or air
conditioners.
Keep dust away from
the machine.
Keep the area
around the
machine clear.
About condensation
If the machine is moved from a cold to a warm place, it is possible that
condensation may form on the scanning glass, preventing proper scanning of
documents. To remove the condensation, turn on the power and wait
approximately two hours before using the machine.
CD-ROM
Setup
Guide
Toner
cartridge
Telephone
line cord
Drum
cartridge
Document
feeder tray
Output tray
