CHECKING PACKED COMPONENTS AND

ACCESSORIES

Open the carton and check if the following components and accessories are

included.

If anything is missing or damaged, contact your authorized service representative.

If the machine does not function properly during setup or use, or if a

function cannot be used, see "TROUBLESHOOTING AND

MAINTENANCE" (p.71).

Note

Drum cartridge

(installed in machine)

Software CD-ROM

Telephone line cord

(AL-1566 only)

• Operation manual

(For Facsimile)

(AL-1566 only)

TD cartridge
