•GETTING STARTED•MAKING COPIES•STATUS INDICATORS•GENERAL INFORMATION•OPTIONAL EQUIPMENT 28223053PLAIN PAPER COPIEROPERATION M

8MAKING COPIESAuditing accountsAUDITING ACCOUNTSIf this copier has been programmed in the auditing mode, it will notfunction until an assigned 3-digit

9MAKING COPIESOne-sided copyingNORMAL COPYINGNormal copying1Turn the power switch on.●It will take about 60 seconds for the copier to warm up. Afterwa

10MAKING COPIESNORMAL COPYING●For manual copy density adjustment, press the EXPOSUREkey to select MANUAL and adjust with the LIGHT and DARKkeys as des

11MAKING COPIESNORMAL COPYING1Place the first original face down on the document glassand close the document cover.2Press the ORIGINAL TO COPY key to

12MAKING COPIESUSING THE MANUAL FEED TRAY (special paper)The manual feed tray is used to copy onto transparency film, labels,tracing paper, and other

13MAKING COPIESTwo-sided copying with manual feed trayTwo-sided copies can be made using the manual feed tray.1Place the first original face down on t

14MAKING COPIESREDUCTION/ENLARGEMENT/ZOOMReduction and enlargement ratios can be selected either auto-matically with the AUTO IMAGE key or manually wi

15MAKING COPIESManual1Place the original face down on the document glass andclose the document cover.2Use the reduction ( ), enlargement ( ) and ZOOMk

16MAKING COPIESDUAL PAGE COPYINGThe DUAL PAGE COPY feature produces separate copies of twodocuments placed side by side on the document glass. It ises

17MAKING COPIES1Place the original face down on the document glass andclose the document cover.●If an optional document feeder (ADF or RADF) is instal

❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧The power switch positions are marked “I” to

18MAKING COPIESMARGIN SHIFTThe MARGIN SHIFT feature automatically shifts the text or image tothe right on one-sided copies to increase the left margin

19MAKING COPIESInterruptINTERRUPTING A COPY RUNINTERRUPT can be used to temporarily stop a long copy run so thatanother job can be run.●Reduction/enla

20MAKING COPIESAutomatic exposure adjustmentAUTOMATIC EXPOSURE ADJUSTMENTThe automatic exposure level can be adjusted to suit your copyingneeds.1Ensur

21MAKING COPIESToner save modeTONER SAVE MODEThis mode reduces toner consumption, increasing cost effective-ness, with only a slight loss in copy dens

22STATUS INDICATORSWhen a misfeed occurs, the copier will stop.The misfeed () indicator will blink and blinkingred misfeed location indicators will in

23STATUS INDICATORSMISFEED REMOVAL Misfeed removalMisfeed in a paper tray1Open the side cover.NOTE:If the transport area misfeed indicator is lighted,

24STATUS INDICATORS2Turn the transport lever to the left.3Turn the roller rotating knob in the direction of the arrowto remove the misfed paper.4Turn

25STATUS INDICATORS2Turn the roller rotating knob in the direction of the arrowand remove the paper from the fusing unit area.CAUTIONThe fusing unit i

26STATUS INDICATORSMISFEED REMOVALMisfeed in the duplex module●The duplex module is optional.NOTE:If any other misfeed locations are indicated, be sur

27STATUS INDICATORS1Open the toner collecting container cover.2Disengage and remove the container from the copier bypushing downward and then pulling

1CONTENTS PageGETTING STARTED●INSTALLATION REQUIREMENTS ...2●CAUTIONS ... 3●LOADING COPY PAPER...

28STATUS INDICATORSWhen the developer replacement required ( ) indicator lights up,the developer should be replaced.DEVELOPER REPLACEMENT SHOULD ONLY

29STATUS INDICATORSMAINTENANCE REQUIREDWhen the maintenance required ( ) indicator lights up, service byan authorized Sharp Service Technician is requ

30GENERAL INFORMATIONPART NAMES AND FUNCTIONSExteriorq Document holderw Exit trayFinished copies are deposited in the exit tray.e Document cover (opti

31GENERAL INFORMATIONPART NAMES AND FUNCTIONSInterior!8 Fusing unitThe fusing unit is hot. Exercise care in this area.!9 Transport leverTurn to open t

32GENERAL INFORMATIONq EDGE ERASE key and indicator (p.17)Use to erase dark areas from copy edges.w MARGIN SHIFT key and indicator (p.18)Shifts text o

33GENERAL INFORMATIONPART NAMES AND FUNCTIONSNOTE: 11" x 17" sized copies are counted astwo copies.#0 Clear (C) keyPress to clear the copy q

34GENERAL INFORMATIONUSER PROGRAMSThe user programs allow the parameters of certain functions to be set,changed, or cancelled as desired.List of user

35GENERAL INFORMATIONSetting the user programs1Press and hold the TRAY SELECT key for more than 5seconds until all the alarm indicators* blink and “–

36GENERAL INFORMATIONUSER PROGRAMS4Select the desired parameter using the 10-key pad.●The entered parameter number will blink on the right side of the

37GENERAL INFORMATIONProgram No. Program name Description10 Auditing mode Enables or disables the auditing mode, which controls access tocopier. See p

2GETTING STARTEDINSTALLATION REQUIREMENTSTo ensure safety and proper machine performance, please note thefollowing before initial installation and whe

38GENERAL INFORMATION3Enter the number 16 using the 10-key pad and press theSTART key.4Choose a new 3-digit code number and enter it using the10-key p

39GENERAL INFORMATIONPOWER SAVESTART12345670C89AUDITING PROGRAMSAuditing programsProgram No. 10: Auditing modeIf the auditing mode is enabled, copying

40GENERAL INFORMATIONProgram No. 12: Account number changeProgram No. 12 is used to change account numbers. When programNo. 12 is entered, an account

41GENERAL INFORMATION100%ZOOM45670C89Program No. 14: Number of copies per accountProgram No. 14 is used to display the total number of copies madeagai

42GENERAL INFORMATIONProgram No. 15: Resetting accountProgram No. 15 is used to reset all accounts or to reset any desiredindividual accounts. When pr

43GENERAL INFORMATIONPOWER SAVE MODESThe copier has two power save modes to reduce overall power consumptionand thereby reduce the cost of operation.

44GENERAL INFORMATIONPower save modesPOWER SAVE MODESSetting the power save modesThe factory default settings for the power save modes are OFF for the

45GENERAL INFORMATIONUser maintenanceUSER MAINTENANCEThe document glass and document cover must be kept clean toavoid dirty areas from being copied on

46GENERAL INFORMATIONCOPIER TROUBLE?Copier trouble?Problem Solution●Copier plugged in? Plug the copier into a grounded outlet.Copier does not operate.

47GENERAL INFORMATIONCOPIER TROUBLE?Copier trouble?Problem Solution●Document glass or document Clean regularly. See page 45.cover dirty?●Original smud

3GETTING STARTEDCAUTIONS1. Do not touch the photoconductive drum. Scratches orsmudges on the drum will cause dirty copies.2. The fusing unit is extrem

48GENERAL INFORMATIONProblem Solution● Is steadily lit in the copy The copier is in the auditing mode. Enterquantity display? your account number us

49GENERAL INFORMATIONSUPPLIES Types and sizes of copy paperORDINARY PAPER●Automatic feeding from the paper trays ormanual feed tray (max. 50 sheets)●M

50GENERAL INFORMATIONSuppliesSUPPLIESGenuine supplies statementStandard SF-2530 supplies replaced by the user include copypaper, toner, toner collecti

51GENERAL INFORMATIONSPECIFICATIONSSpecificationsCOPIERType DesktopCopy system Dry, electrostatic transfer systemOriginals Sheets, bound documentsOrig

52GENERAL INFORMATIONSPECIFICATIONSOverall dimensions 47-29/64" (W) x 25-19/32" (D)(1205 mm (W) x 650 mm (D))Weight (with Approx. 142.0 lbs.

53ADF (SF-A17)/RADF (SF-A56)ADF (SF-A17)/RADF (SF-A56)OPTIONAL EQUIPMENTCONTENTS Page●SYSTEM CONFIGURATION ... 54●AUTOMAT

54ADF (SF-A17)/RADF (SF-A56)OPTIONAL EQUIPMENTADF (SF-A17)/RADF (SF-A56)SYSTEM CONFIGURATIONThe options which are available for the SF-2530 are shown

55ADF (SF-A17)/RADF (SF-A56)ADF (SF-A17)/RADF (SF-A56)OPTIONAL EQUIPMENTAUTOMATIC DOCUMENT FEEDER (SF-A17)REVERSING AUTOMATIC DOCUMENT FEEDER (SF-A56)

56ADF (SF-A17)/RADF (SF-A56)OPTIONAL EQUIPMENTADF (SF-A17)/RADF (SF-A56)Stream feeding modeThe stream feeding mode allows easy operation of continuous

57ADF (SF-A17)/RADF (SF-A56)ADF (SF-A17)/RADF (SF-A56)OPTIONAL EQUIPMENT2Ensure that the 1-sided to 1-sided copying mode isselected in the ORIGINAL TO

4GETTING STARTEDThe paper required ( ) indicator will light up whenthere is no copy paper in a selected paper feed stationor when a selected paper tra

58ADF (SF-A17)/RADF (SF-A56)OPTIONAL EQUIPMENTADF (SF-A17)/RADF (SF-A56)3Enter the desired number of copies.●The maximum number of copies in the two-s

59ADF (SF-A17)/RADF (SF-A56)ADF (SF-A17)/RADF (SF-A56)OPTIONAL EQUIPMENT3Enter the desired number of copies.●The maximum number of copies in the two-s

60ADF (SF-A17)/RADF (SF-A56)OPTIONAL EQUIPMENTADF (SF-A17)/RADF (SF-A56)Misfeed removalLocation CLocation BLocation AAn original misfeed may occur at

61OPTIONAL EQUIPMENT10-BIN SORTER (SF-S18)20-BIN SORTER (SF-S15)There are two sorter modes for different copying jobs: one sortscopies into sets match

62OPTIONAL EQUIPMENT10-BIN SORTER (SF-S18)/ 20-BIN SORTER (SF-S15)GROUPSORTUsing a sorter10-bin sorter (SF-S18)20-bin sorter (SF-S15)Press the SORTER

63OPTIONAL EQUIPMENTSORTER CAPACITIESSF-S18 SF-S15Top bin Top bin100 sheets in the NON-SORT mode 100 sheets in the NON-SORT modeSort binsSORT mode:Pap

64OPTIONAL EQUIPMENTMisfeed removalThe copier will stop when a misfeed occurs. The misfeed ( )indicator will blink and blinking red misfeed location i

65OPTIONAL EQUIPMENT20-BIN SORTER (SF-S15)20-bin sorter (SF-S15)SF-S15 20-bin sorter1Open the top cover and remove the misfed paper.2Close the top co

66OPTIONAL EQUIPMENTSF-S15No. of bins 20Bin capacity NON-SORT: 100 sheets (top bin)SORT: 50 sheetsGROUP: 30 sheetsPaper size Top bin: Max. 11" x

67OPTIONAL EQUIPMENTPART NAMESSF-S54NSF-S5610-bin staple sorter (SF-S54N)20-bin staple sorter (SF-S56)10-BIN STAPLE SORTER (SF-S54N)20-BIN STAPLE SORT

5GETTING STARTEDChanging the lower paper tray’s inner cassetteThe lower paper tray can accommodate five different paper sizes. Tochange the paper size

68OPTIONAL EQUIPMENT10-bin staple sorter (SF-S54N)20-bin staple sorter (SF-S56)10-BIN STAPLE SORTER (SF-S54N)/ 20-BIN STAPLE SORTER (SF-S56)GROUPSORT(

69OPTIONAL EQUIPMENTMax. No. Max. No.Mode Paper sizeof of copiesoriginals to be setMin.:NON- 5-1/2" x 8-1/2"–99SORT Max.:11" x 17"

70OPTIONAL EQUIPMENTStapling location10-bin staple sorter (SF-S54N)20-bin staple sorter (SF-S56)Staple sortThe STAPLE SORT mode staples copies of 5-1/

71OPTIONAL EQUIPMENT(ORIGINALS)EVEN NUMBEODD NUMBERPRE-COUNTORIGINALSSORTSTAPLESORTGROUP9STARTUsing the ADF or RADF1Set the originals in the document

72OPTIONAL EQUIPMENT1Align the edges of the copies to be stapled.2Place the set of copies into the top bin, making sure theedges are flush with the in

73OPTIONAL EQUIPMENTSTAPLE TEAR lineStaple cartridge replacementThe CHECK STAPLER indicator will blink when the staple cartridgeis empty and the copie

74OPTIONAL EQUIPMENTSF-S56 20-bin staple sorter1Open the stapler cover.2Lift the release lever and pull out the staple box.●Lift the release lever to

75OPTIONAL EQUIPMENT5Remove the rear paper and tape from the cartridge.●Pull them straight. If they are pulled obliquely, the tape may betorn.6Insert

76OPTIONAL EQUIPMENTStaple jam removalIf staples become jammed in the stapler, the CHECK STAPLERindicator and the STAPLE SORT mode indicator will blin

77OPTIONAL EQUIPMENTSF-S56 20-bin staple sorter1Open the stapler cover.2Lift the release lever and pull out the staple box.●Lift the release lever to

6GETTING STARTED1Open the front cover.2Pull down the toner hopper lock lever and pull the tonerhopper out slowly until it stops.3Hold the toner cartri

78OPTIONAL EQUIPMENT5Insert the staple box into the stapler unit until it clicks inplace.6Close the stapler cover.7Following the stapling procedure on

79OPTIONAL EQUIPMENTMisfeed removalThe copier will stop when a misfeed occurs. The misfeed ( )indicator will blink and blinking red misfeed location i

80OPTIONAL EQUIPMENTSF-S56 20-bin staple sorter1Push the sorter release button and slide the sortercarefully along the guides away from the copier.2Re

81OPTIONAL EQUIPMENTSpecificationsSF-S54NNo. of bins 10Bin capacity NON-SORT: 100 sheets (top bin)SORT/ 30 sheets (5-1/2" x 8-1/2", 8-1/2&qu

82OPTIONAL EQUIPMENTSTAND/500-SHEET PAPER DRAWER (SF-D20)STAND/1000-SHEET PAPER DRAWER (SF-D21)These optional stands with paper trays provide the conv

83OPTIONAL EQUIPMENTStand/500-sheet paper drawer (SF-D20)1Gently lift and pull out the 500-sheet paper drawer.2Fan the copy paper and insert it in the

84OPTIONAL EQUIPMENT1Open the side cover and remove any misfed paper.●Be sure to perform this step before pulling out either of the paperdrawers. If n

85OPTIONAL EQUIPMENTSTAND/500-SHEET PAPER DRAWER (SF-D20)/STAND/1000-SHEET PAPER DRAWER (SF-D21)SpecificationsStand/500-sheet paper drawer (SF-D20)Sta

86OPTIONAL EQUIPMENTMEMODownloaded From ManualsPrinter.com Manuals

87OPTIONAL EQUIPMENTAUDITOR CODE NUMBER:FACTORY SETTINGThe following is the factory setting of the Auditor CodeNumber, which must be used to access th

7GETTING STARTED4Place the new toner cartridge with the tabs in thenotches as shown.5Slide the toner cartridge along the guides over the tonerhopper.6

99C DSC3CINSE1807FC51Downloaded From ManualsPrinter.com Manuals

WARNING:FCC Regulations state that any unauthorized changes or modifications tothis equipment not expressly approved by the manufacturer could void th

PRINTED IN HONG KONG99A KSqTINSE1807FCZZSF-2530SHARP ELECTRONICS CORPORATIONSharp Plaza, Mahwah, New Jersey 07430-2135.SHARP CORPORATIONSF-
