CHANGING THE PORT

Select [SC TCP/IP Port] and then click

the [New Port] button.

In Windows 98/Me, select [Other], [SC TCP/IP Port], and

then click the [OK] button.

Create the new port.

(1) Enter the machine's IP address.

☞ CHECKING THE IP ADDRESS OF THE MACHINE

(page 7)

(2) Make sure that [LPR] is selected.

(3) Make sure that [lp] is entered.

(4) Click the [OK] button.

Click the [Close] button in the screen of

step 4.

In Windows 98/Me, this step is not required. Go to the

next step.

Make sure the created printer port is

selected in the printer properties

window and then click the [Apply]

button.

• The "SC TCP/IP Port" is added when the printer

driver is installed using a "Standard installation", or

a "Custom installation" with "LPR Direct Print"

selected.

• If the printer driver is installed using a "Custom

installation" with "IPP" selected, the [SC-Print2005

Port] is added. If you need to change the printer port

when the machine is connected to an intranet or a

wide area network (WAN) using the IPP function,

select [SC-Print2005 Port], click the [New Port]

button (the [OK] button in Windows 98/Me), and

follow the on-screen instructions to create the port

again.

(4)

(1) (2) (3)
