INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER

Configure the image of the machine.

An image of the machine is formed in the printer driver

configuration window based on the options that are

installed.

(1) Select the options that are installed on

the machine.

(2) Click the [OK] button.

Click the [OK] button in the printer

properties window.

To cancel the image settings, click the [Cancel]

button.

(1)

(2)

If automatic configuration fails

• You can check the options that are installed and the tray settings by printing out the "All Custom Setting List" in the system

settings of the machine. (However, note that "Input Tray Options" must be set to the number of trays on the machine.)

Follow these steps to print out the "All Custom Setting List": Press the [SYSTEM SETTINGS] key, touch the [List Print

(User)] key, and then touch the [Print] key of "All Custom Setting List".

• Click the [Set Tray Status] button, the [Paper Type Name] button, and the [Set Tandem Print]* button to check the settings

of each.

Set Tray Status: The "Tray Settings" in "Paper Tray Settings" in system settings of the machine are reflected in the

settings shown here. Specify the size and type of paper loaded in each tray.

Paper Type Name: The "Paper Type Registration" settings in "Paper Tray Settings" in the system settings of the machine

are reflected in the settings shown here. If a user type name (1 to 7) was changed, enter the changed

name.

Set Tandem Print*: Enter the setting (the IP address of the slave machine) in "Tandem Connection Setting" in the system

settings (administrator) of the machine.

* "Set Tandem Print" can only be configured when the printer driver is installed using a "Standard installation" or a "Custom

installation" with "LPR Direct Print (Specify Address/Auto Search)" selected.
