136
TROUBLESHOOTING AND MAINTENANCE
Removing staple jams
Follow the steps below to remove a staple jam.
1
Open the cover.
2
While pressing the lever over to the
left, slide the finisher to the left until it
stops.
Gently slide the finisher
until it stops.
3
Lower the staple case release lever
and remove the staple case.
Pull the staple case out
to the right.
4
Raise the lever at the front end of the
staple case and remove the jammed
staple.
Remove the leading
staple if it is bent. If bent
staples remain, a staple
jam will occur again.
5
Lower the lever at the front end of the
staple case.
6
Replace the staple case.
Push the staple case in
until it clicks into place.
7
Slide the finisher back to the right.
Gently slide the finisher
back to the right until it
locks into its original
position.
8
Close the cover.
Take care that a bent staple does not hurt
you.
Caution
