REMOTE OPERATION VIA A NETWORK

3-9

Directly printing a file on an FTP server

A FTP server can be stored in the machine to enable direct printing of a file on the FTP server from the operation

panel of the machine without using the printer driver.

Files with the extensions pcl, ps*, pdf*, tiff, tif, and prn can be printed.

*The PS3 expansion kit is required.

■

■■

■ Storing an FTP server

To directly print a file on an FTP server, the FTP server must be stored.

Follow these steps:

Click [Pull Print (Panel)] in the link menu of

the menu frame.

The "Pull Print (Panel)" page appears.

Store the FTP server information in [FTP

Server Setup].

For more information, click the [General] button in

the [Help] in the menu frame.

Enter the FTP server information.

For more information, click the [General] button in

the [Help] in the menu frame.

Click [submit] to store the entered

information.

■

■■

■ Printing a file on an FTP server from the operation panel of the machine

Press the [DOCUMENT FILING] key twice

to display the global access screen.

Touch the [FTP] key.

This screen will not

appear if an FTP server

has not been stored.

Select the desired FTP server.

GLOBAL ACCESS

FTP

GLOBAL ACCESS

FTP

Technical dept. server

PPD1_FTP_server
