AR-M236AR-M237AR-M276AR-M277MODELDIGITAL MULTIFUNCTIONAL SYSTEMSOFTWARE SETUP GUIDEPage• INTRODUCTION• SOFTWARE FOR THE SHARP AR-M230/M270 SERIES• BE

8INSTALLING THE SOFTWARE11When the interface selection screen appears, select "USB" and click the "Next" button.12A confirmation w

9INSTALLING THE SOFTWAREInstallation in Windows 95/98/Me/NT 4.0/2000 (Parallel cable)1The parallel cable must not be connected to the machine. Make su

10INSTALLING THE SOFTWARE11When the interface selection screen appears, select "Parallel" and click the "Next" button.12Select the

11INSTALLING THE SOFTWAREINSTALLING THE PC-FAX DRIVER1The USB or parallel cable must not be connected to the machine. Make sure that the cable is not

12CONNECTING TO A COMPUTERFollow the procedure below to connect the machine to your computer.Interface cables for connecting the machine to your compu

13CONFIGURING THE PRINTER DRIVERAfter installing the printer driver, you must configure the printer driver settings appropriately for the number of pa

14HOW TO USE THE ONLINE MANUALThe online manual provides detailed instructions for operating the machine as a printer. View the online manual when you

15TROUBLESHOOTINGIf the software does not install correctly, check the following items on your computer.To remove the software, see "Uninstalling

16TROUBLESHOOTINGThe printer driver cannot be correctly installed by Plug and Play (Windows 2000/XP)In Windows 2000/XP, if the printer driver cannot b

!!install_ar230270.book 1 ページ ２００４年２月１９日　木曜日　午後１時１７分

INTRODUCTIONThis manual explains how to install and configure the software that is required for the printer function of the machine. The procedure for

PRINTED IN CHINA2004C KS2TINSE1053QSZZAR-M236/AR-M237/AR-M276/AR-M277SHARP CORPORATIONPrinted on 100% post-consumer recycled paper!!install_ar230270.b

1CONTENTSSOFTWARE FOR THE SHARP AR-M230/M270 SERIES... 2BEFORE INSTALLATION ...

2SOFTWARE FOR THE SHARP AR-M230/M270 SERIESThe CD-ROM that accompanies the machine contains the following software:• Printer driverThe printer driver

3INSTALLING THE SOFTWARESTANDARD INSTALLATION (USB only)The procedure for a standard installation of the software is explained below. If the machine i

4INSTALLING THE SOFTWARE9Make sure that the power of the machine is turned on, and then connect the USB cable. (p. 12)Windows will detect the machine

5INSTALLING THE SOFTWARECUSTOM INSTALLATIONThe procedure for a custom installation of the software is explained below. Use the custom installation pro

6INSTALLING THE SOFTWARE10When you are asked how the printer is connected, select "Connected to this computer" and click the "Next"

7INSTALLING THE SOFTWAREInstallation in Windows 98/Me/2000 (USB cable)1The USB cable must not be connected to the machine. Make sure that the cable is
