MISFEED REMOVAL

When the misfeed ( ) indicator blinks or blinks in the display, the unit will

stop because of a misfeed.

Open the side cover, in that order.

To open the side cover, see "TONER CARTRIDGE REPLACEMENT"

(p.21).

Check the misfeed location. Remove the misfed paper

following the instructions for each location in the illustration

below. If the misfeed ( ) indicator blinks, proceed to "A:

Misfeed in the paper feed area" (p.29).

If paper is misfed here, proceed to "A:

Misfeed in the paper feed area". (p.29)

If paper is misfed here, proceed to "B:

Misfeed in the fusing area". (p.29)

If the misfed paper is seen from

this side, proceed to "C: Misfeed

in the transport area". (p.30)
