MAIN FEATURES
1-5
1
Job Build See page 5-8
When you have a very large number of originals, the
pages can be scanned in sets.
Tandem Copy See page 5-9
Two machines can be used to run a large copy job
in parallel.
Covers/inserts See page 5-11
Front covers, back covers, and inserts can be
added. These can also be copied on.
Transparency Insert See page 5-22
Inserts can be automatically inserted between
transparencies.
Multi Shot See page 5-23
Multiple original pages can be copied onto a
single sheet of paper in a uniform layout.
Book Copy See page 5-25
Books and other bound originals can be copied
pamphlet style.
150 sheets300 sheets 150 sheets
100 sheets 50 sets of
copies
50 sets of
copies
*AR-M550N or AR-M620N only.
Front cover
Back cover
Originals
Insert sheets
Insert sheets
Originals (1-sided)
Originals (2-sided)
Copy
Originals
(1-sided)
Originals
(2-sided)
Copy
CopyOriginal
Left binding
Right binding
First page
First page
First page
First page
