13

Local Installation

Parallel

Connect to the Computer

□ Turn off both the computer and the printer.

Attach a standard IEEE-1284 parallel cable (not supplied) to the parallel port on the printer (1), securing it with the spring

clips.

Attach the other end to the parallel port on the computer (2) and secure it in place with the screws.

Parallel_Connect_1.tif
